KEY SPECIFICATION FEATURES:
- Conforms to API 675 Standards
- Steady State Accuracy of :t 1 %
- Turn Down Ratio 10:1
- Repeatability :t3%
- Linearity :t3%
- Long. life, rugged construction, cast.iron
- gear box housing.
- Acurate flow adjustment through 20 turn knob
- rotation
- Amplitude Modulated Positive Stroke return
- by Double Eccentric Mechanism
- Manual or automatic flow control, adjustable
- while running or stopped.
- All moving parts operate in an oil bath.
- Reduced friction wear
- High precision balls and seats for reiiability &
- accuracy
- Plunger size available between 16 mm
- to 90 mm
- End connections available in both threaded &
- Fianged Versions
- Maximum Liquid Temperature. 120′C
- Maximum Ambient Temperature. 50′C
- Liquid End Material of Construction in SS. 316
- Capacity adjustment by
1. Micrometer. Standard
2. Variable Speed Drive. Optional
